Capacity Tables (Heat Pump High COP Series) ED34-645B
602 RXYQ-PH
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(630)
-19.8 -20.0 69.1 29.1 68.9 29.8 68.8 30.5 68.7 30.9 68.6 31.3 68.5 32.0
-18.8 -19.0 70.3 29.3 70.2 30.0 70.1 30.8 70.0 31.1 69.9 31.5 68.6 31.4
-16.7 -17.0 73.1 29.8 73.0 30.5 72.9 31.2 72.8 31.5 72.7 31.9 68.6 29.9
-13.7 -15.0 76.2 30.3 76.1 31.0 76.0 31.7 75.9 32.0 73.7 30.9 68.6 28.3
-11.8 -13.0 79.7 30.9 79.5 31.5 78.8 31.7 76.2 30.5 73.7 29.2 68.6 26.8
-9.8 -11.0 83.4 31.4 83.3 32.0 78.8 29.9 76.2 28.8 73.7 27.6 68.6 25.4
-9.5 -10.0 85.4 31.6 83.8 31.4 78.8 29.1 76.2 28.0 73.7 26.8 68.6 24.7
-8.5 -9.1 87.2 31.9 83.8 30.5 78.8 28.3 76.2 27.2 73.7 26.1 68.6 24.1
-7.0 -7.6 88.9 31.3 83.8 29.2 78.8 27.1 76.2 26.0 73.7 25.0 68.6 23.0
-5.0 -5.6 88.9 29.5 83.8 27.5 78.8 25.5 76.2 24.5 73.7 23.6 68.6 21.7
-3.0 -3.7 88.9 27.8 83.8 25.9 78.8 24.1 76.2 23.2 73.7 22.3 68.6 20.6
0.0 -0.7 88.9 25.3 83.8 23.6 78.8 22.0 76.2 21.2 73.7 20.4 68.6 18.9
3.0 2.2 88.9 23.2 83.8 21.7 78.8 20.2 76.2 19.5 73.7 18.8 68.6 17.4
5.0 4.1 88.9 21.9 83.8 20.5 78.8 19.1 76.2 18.4 73.7 17.8 68.6 16.5
7.0 6.0 88.9 20.7 83.8 19.4 78.8 18.1 76.2 17.5 73.7 16.8 68.6 15.6
9.0 7.9 88.9 19.6 83.8 18.4 78.8 17.2 76.2 16.6 73.7 16.0 68.6 14.8
11.0 9.8 88.9 18.5 83.8 17.4 78.8 16.3 76.2 15.7 73.7 15.2 68.6 14.1
13.0 11.8 88.9 17.5 83.8 16.5 78.8 15.4 76.2 14.9 73.7 14.4 68.6 13.4
15.0 13.7 88.9 16.6 83.8 15.6 78.8 14.7 76.2 14.2 73.7 13.7 68.6 12.8
60
(540)
-19.8 -20.0 68.7 30.9 68.6 31.5 67.5 31.4 65.3 30.2 63.2 29.0 58.8 26.6
-18.8 -19.0 70.0 31.1 69.9 31.7 67.5 30.7 65.3 29.5 63.2 28.3 58.8 26.0
-16.7 -17.0 72.8 31.6 71.8 31.6 67.5 29.3 65.3 28.1 63.2 27.0 58.8 24.8
-13.7 -15.0 75.9 32.0 71.8 30.0 67.5 27.8 65.3 26.7 63.2 25.7 58.8 23.6
-11.8 -13.0 76.2 30.5 71.8 28.4 67.5 26.3 65.3 25.3 63.2 24.3 58.8 22.4
-9.8 -11.0 76.2 28.8 71.8 26.8 67.5 24.9 65.3 24.0 63.2 23.0 58.8 21.2
-9.5 -10.0 76.2 27.9 71.8 26.0 67.5 24.2 65.3 23.3 63.2 22.4 58.8 20.7
-8.5 -9.1 76.2 27.2 71.8 25.4 67.5 23.6 65.3 22.7 63.2 21.9 58.8 20.2
-7.0 -7.6 76.2 26.0 71.8 24.3 67.5 22.6 65.3 21.8 63.2 21.0 58.8 19.3
-5.0 -5.6 76.2 24.5 71.8 22.9 67.5 21.3 65.3 20.6 63.2 19.8 58.8 18.3
-3.0 -3.7 76.2 23.2 71.8 21.7 67.5 20.2 65.3 19.5 63.2 18.8 58.8 17.4
0.0 -0.7 76.2 21.2 71.8 19.8 67.5 18.5 65.3 17.9 63.2 17.2 58.8 16.0
3.0 2.2 76.2 19.5 71.8 18.2 67.5 17.1 65.3 16.5 63.2 15.9 58.8 14.8
5.0 4.1 76.2 18.4 71.8 17.3 67.5 16.2 65.3 15.6 63.2 15.1 58.8 14.0
7.0 6.0 76.2 17.5 71.8 16.4 67.5 15.3 65.3 14.8 63.2 14.3 58.8 13.3
9.0 7.9 76.2 16.6 71.8 15.6 67.5 14.6 65.3 14.1 63.2 13.6 58.8 12.7
11.0 9.8 76.2 15.7 71.8 14.8 67.5 13.9 65.3 13.4 63.2 13.0 58.8 12.1
13.0 11.8 76.2 14.9 71.8 14.0 67.5 13.2 65.3 12.7 63.2 12.3 58.8 11.5
15.0 13.7 76.2 14.2 71.8 13.4 67.5 12.5 65.3 12.1 63.2 11.8 58.8 11.0
50
(450)
-19.8 -20.0 63.5 29.2 59.9 27.2 56.3 25.2 54.4 24.3 52.6 23.4 49.0 21.5
-18.8 -19.0 63.5 28.5 59.9 26.6 56.3 24.7 54.4 23.8 52.6 22.9 49.0 21.1
-16.7 -17.0 63.5 27.2 59.9 25.3 56.3 23.6 54.4 22.7 52.6 21.8 49.0 20.1
-13.7 -15.0 63.5 25.8 59.9 24.1 56.3 22.4 54.4 21.6 52.6 20.8 49.0 19.2
-11.8 -13.0 63.5 24.5 59.9 22.9 56.3 21.3 54.4 20.5 52.6 19.8 49.0 18.3
-9.8 -11.0 63.5 23.2 59.9 21.7 56.3 20.2 54.4 19.5 52.6 18.8 49.0 17.4
-9.5 -10.0 63.5 22.5 59.9 21.1 56.3 19.7 54.4 19.0 52.6 18.3 49.0 16.9
-8.5 -9.1 63.5 22.0 59.9 20.6 56.3 19.2 54.4 18.5 52.6 17.8 49.0 16.5
-7.0 -7.6 63.5 21.1 59.9 19.7 56.3 18.4 54.4 17.8 52.6 17.1 49.0 15.9
-5.0 -5.6 63.5 19.9 59.9 18.7 56.3 17.4 54.4 16.8 52.6 16.2 49.0 15.1
-3.0 -3.7 63.5 18.9 59.9 17.7 56.3 16.5 54.4 16.0 52.6 15.4 49.0 14.3
0.0 -0.7 63.5 17.3 59.9 16.3 56.3 15.2 54.4 14.7 52.6 14.2 49.0 13.2
3.0 2.2 63.5 16.0 59.9 15.0 56.3 14.1 54.4 13.6 52.6 13.2 49.0 12.3
5.0 4.1 63.5 15.2 59.9 14.3 56.3 13.4 54.4 13.0 52.6 12.5 49.0 11.7
7.0 6.0 63.5 14.4 59.9 13.6 56.3 12.7 54.4 12.3 52.6 11.9 49.0 11.1
9.0 7.9 63.5 13.7 59.9 12.9 56.3 12.1 54.4 11.8 52.6 11.4 49.0 10.6
11.0 9.8 63.5 13.0 59.9 12.3 56.3 11.6 54.4 11.2 52.6 10.9 49.0 10.2
13.0 11.8 63.5 12.4 59.9 11.7 56.3 11.0 54.4 10.7 52.6 10.4 49.0 9.7
15.0 13.7 63.5 11.8 59.9 11.2 56.3 10.5 54.4 10.2 52.6 9.9 49.0 9.3
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
