Control Devices ED34-645B
798 Control
4.9.1 System Image
An Overview of the intelligent Manager III System
4.9.2 Series and Components
The intelligent Manager III Series and its Components
∗1 Products name is recognized as an order number. This includes hardware, software and field engineering work
as a package.
∗2 kWh meters to be locally supplied.
∗3 With the PPD system, data is transferred from the indoor units and compared with reference data on the
standard power consumption of air conditioning equipment under normal conditions.
The results are used to estimate the power consumption of each indoor unit. Note, however, that this
measurement method is exclusive to Daikin and has no legal basis.
Products name ∗1 IM-128 IM-256 IM-512 IM-768 IM-1024
Max number indoor units 128 256 512 768 1024
Max number outdoor units 20 40 80 120 160
PC, UPS, etc. Local Procurement
Hardware model name ∗2
DAM602B52 DAM602B51×1 DAM602B51×2 DAM602B51×3 DAM602B51×4
PPD (Power Proportional Distribution)
∗3Yes ∗2
HRV
Contact Signal
[Air-conditioning systems]
[
Local Monitoring & Control
]
Ethernet
Remote Error
Monitoring
Remote Monitoring
Via Modem
Wiring adaptor required for
connection with other
equipment not compatible
with
Daikin Central
∗3
Air Conditioning System
Outdoor
Unit
Indoor Unit
Remote
Controller
Maximum of 64 Groups
iPU
Security Fire alarm
Remote Access
Remote Monitoring
Via LAN
Via Internet
DAM602B51
∗2
DAM602B51
∗2
DAM602B51
∗2
DAM602B51
∗2
∗
3
Interfacing requirements vary depending on model, and some systems may not be suitable. Please contact your distributor for details.
∗
2
Model no varies upon the system size.
Remote
Manager
Remote Access
Via Modem
∗
1
There are restrictions in applicable areas and release times, therefore please consult us separately for details.
Air-Conditioning
Network Service System
∗1
Optional Maintenance
Service
Light
Dio Unit DEC102A51
Di Unit DEC101A51
Pump Fan
D Ai unit
DAM101A51
NEW
NEW
