Control Devices ED34-645B
720 Control
4. Control Devices
4.1 <BRC1C62> Wired Remote Controller
You can construct a versatile control system that can respond to various applications by taking advantage of the
optional accessory liquid crystal remote controller for indoor units.
Remote controller wiring for transmission for a simplified remote controller (BRC2C51 (BRC2A51), BRC3A61) is the
same as that of a standard remote controller (BRC1C62). Because the functions of the simplified remote controller
are limited, we recommend using in combination with a central remote controller.
4.1.1 Appearance and Functions
Note: For connection unit series
∗ If indoor units from the Connection unit series are connected within a single refrigerant system to indoor units from
any other series, cooling/heating switchover will not be possible using the remote contoroller of the Connection
unit series indoor units, However, if the remote controller of an indoor unit from the other series is set as a master
remote controller, cooling/heating switchover will be possible.
∗ If all indoor units are from the Connection unit series, an outdoor unit Cool/Heat selector will be needed to enable
cooling/heating switchover.
∗ In case of Heat Recovery System
Cooling/Heating changeover is possible when connecting with BS unit.
4.1.2 Example of Control by Remote Controller
Large liquid crystal screen displays complete operating status.
Digital display lets you set temperature in 1°C units.
Lets you individually program by timer the respective times for operation start and stop
within a maximum of 72 hours.
Equipped with a thermostat sensor in the remote controller that makes possible more
comfortable room temperature control.
Monitors room temperature and preset temperature by microcomputer, and can select
cool/heat operation mode automatically. (VRV System Heat Recovery Series only)
Enables you to select cool / heat / fan operation mode with the indoor remote controller of
your choice without using the cool / heat selector. (VRV System Inverter series, Heat
Recovery series, Plus series)
Constantly monitors malfunctions in the system for 40 items, and is equipped with a “self-
diagnosis function” that lets you know by message immediately when a malfunction occurs.
Lets you carry out various field settings by remote controller.
Ventilation mode change over and ventilation air flow switch for HRV.
