Capacity Tables (Heat Pump High COP Series) ED34-645B
616 RXYQ-PH
a
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(875)
-19.8 -20.0 89.9 39.2 89.7 40.3 89.5 41.4 89.4 42.0 89.3 42.5 89.1 43.7
-18.8 -19.0 91.5 39.6 91.3 40.7 91.2 41.8 91.1 42.3 91.0 42.9 90.8 43.9
-16.7 -17.0 95.2 40.4 95.0 41.4 94.8 42.4 94.7 43.0 94.6 43.5 94.4 44.5
-13.7 -15.0 99.2 41.1 99.0 42.1 98.8 43.1 98.7 43.6 98.6 44.1 95.2 42.8
-11.8 -13.0 103.7 41.9 103.5 42.9 103.3 43.8 103.2 44.3 102.2 44.2 95.2 40.6
-9.8 -11.0 109 42.7 108 43.6 108 44.5 106 43.5 102.2 41.7 95.2 38.4
-9.5 -10.0 111 43.1 111 44.0 109 43.9 106 42.2 102.2 40.6 95.2 37.3
-8.5 -9.1 114 43.5 113 44.3 109 42.8 106 41.1 102.2 39.5 95.2 36.3
-7.0 -7.6 118 44.0 116 44.1 109 40.9 106 39.3 102.2 37.8 95.2 34.8
-5.0 -5.6 123 44.5 116 41.5 109 38.5 106 37.1 102.2 35.6 95.2 32.8
-3.0 -3.7 123 42.0 116 39.1 109 36.4 106 35.0 102.2 33.7 95.2 31.1
0.0 -0.7 123 38.3 116 35.7 109 33.3 106 32.0 102.2 30.8 95.2 28.5
3.0 2.2 123 35.0 116 32.7 109 30.5 106 29.4 102.2 28.3 95.2 26.2
5.0 4.1 123 33.1 116 30.9 109 28.9 106 27.9 102.2 26.8 95.2 24.9
7.0 6.0 123 31.3 116 29.3 109 27.3 106 26.4 102.2 25.4 95.2 23.6
9.0 7.9 123 29.6 116 27.7 109 25.9 106 25.0 102.2 24.1 95.2 22.4
11.0 9.8 123 28.0 116 26.3 109 24.6 106 23.8 102.2 22.9 95.2 21.3
13.0 11.8 123 26.5 116 24.9 109 23.3 106 22.5 102.2 21.7 95.2 20.2
15.0 13.7 123 25.2 116 23.6 109 22.2 106 21.4 102.2 20.7 95.2 19.3
60
(750)
-19.8 -20.0 89.4 42.0 89.2 42.9 89.1 43.9 89.0 44.4 87.6 43.8 81.6 40.2
-18.8 -19.0 91.1 42.3 90.9 43.2 90.7 44.2 90.6 44.6 87.6 42.8 81.6 39.3
-16.7 -17.0 94.7 43.0 94.5 43.9 93.6 44.2 90.6 42.5 87.6 40.8 81.6 37.5
-13.7 -15.0 98.7 43.6 98.6 44.5 93.6 42.0 90.6 40.4 87.6 38.8 81.6 35.7
-11.8 -13.0 103.2 44.3 99.6 42.8 93.6 39.8 90.6 38.3 87.6 36.8 81.6 33.9
-9.8 -11.0 106 43.5 99.6 40.5 93.6 37.6 90.6 36.2 87.6 34.8 81.6 32.1
-9.5 -10.0 106 42.2 99.6 39.4 93.6 36.6 90.6 35.2 87.6 33.9 81.6 31.2
-8.5 -9.1 106 41.1 99.6 38.3 93.6 35.6 90.6 34.3 87.6 33.0 81.6 30.5
-7.0 -7.6 106 39.3 99.6 36.7 93.6 34.1 90.6 32.9 87.6 31.7 81.6 29.2
-5.0 -5.6 106 37.0 99.6 34.6 93.6 32.2 90.6 31.1 87.6 29.9 81.6 27.7
-3.0 -3.7 106 35.0 99.6 32.7 93.6 30.5 90.6 29.4 87.6 28.3 81.6 26.2
0.0 -0.7 106 32.0 99.6 30.0 93.6 28.0 90.6 27.0 87.6 26.0 81.6 24.1
3.0 2.2 106 29.4 99.6 27.6 93.6 25.8 90.6 24.9 87.6 24.0 81.6 22.3
5.0 4.1 106 27.8 99.6 26.1 93.6 24.4 90.6 23.6 87.6 22.8 81.6 21.2
7.0 6.0 106 26.4 99.6 24.8 93.6 23.2 90.6 22.4 87.6 21.6 81.6 20.1
9.0 7.9 106 25.0 99.6 23.5 93.6 22.0 90.6 21.3 87.6 20.6 81.6 19.2
11.0 9.8 106 23.7 99.6 22.3 93.6 20.9 90.6 20.3 87.6 19.6 81.6 18.3
13.0 11.8 106 22.5 99.6 21.2 93.6 19.9 90.6 19.3 87.6 18.6 81.6 17.4
15.0 13.7 106 21.4 99.6 20.2 93.6 19.0 90.6 18.4 87.6 17.8 81.6 16.6
50
(625)
-19.8 -20.0 88.0 44.1 83.0 41.1 78.0 38.1 75.5 36.7 73.0 35.3 68.0 32.5
-18.8 -19.0 88.0 43.1 83.0 40.2 78.0 37.3 75.5 35.9 73.0 34.5 68.0 31.8
-16.7 -17.0 88.0 41.1 83.0 38.3 78.0 35.6 75.5 34.3 73.0 33.0 68.0 30.4
-13.7 -15.0 88.0 39.0 83.0 36.4 78.0 33.9 75.5 32.6 73.0 31.4 68.0 29.0
-11.8 -13.0 88.0 37.0 83.0 34.6 78.0 32.2 75.5 31.0 73.0 29.9 68.0 27.6
-9.8 -11.0 88.0 35.0 83.0 32.7 78.0 30.5 75.5 29.4 73.0 28.4 68.0 26.2
-9.5 -10.0 88.0 34.1 83.0 31.9 78.0 29.7 75.5 28.7 73.0 27.6 68.0 25.6
-8.5 -9.1 88.0 33.2 83.0 31.1 78.0 29.0 75.5 28.0 73.0 27.0 68.0 25.0
-7.0 -7.6 88.0 31.8 83.0 29.8 78.0 27.8 75.5 26.9 73.0 25.9 68.0 24.0
-5.0 -5.6 88.0 30.1 83.0 28.2 78.0 26.3 75.5 25.4 73.0 24.5 68.0 22.8
-3.0 -3.7 88.0 28.5 83.0 26.7 78.0 25.0 75.5 24.1 73.0 23.3 68.0 21.6
0.0 -0.7 88.0 26.2 83.0 24.6 78.0 23.0 75.5 22.3 73.0 21.5 68.0 20.0
3.0 2.2 88.0 24.1 83.0 22.7 78.0 21.3 75.5 20.6 73.0 19.9 68.0 18.5
5.0 4.1 88.0 22.9 83.0 21.6 78.0 20.2 75.5 19.6 73.0 18.9 68.0 17.7
7.0 6.0 88.0 21.8 83.0 20.5 78.0 19.3 75.5 18.6 73.0 18.0 68.0 16.8
9.0 7.9 88.0 20.7 83.0 19.5 78.0 18.3 75.5 17.8 73.0 17.2 68.0 16.1
11.0 9.8 88.0 19.7 83.0 18.6 78.0 17.5 75.5 16.9 73.0 16.4 68.0 15.4
13.0 11.8 88.0 18.7 83.0 17.7 78.0 16.6 75.5 16.1 73.0 15.6 68.0 14.7
15.0 13.7 88.0 17.9 83.0 16.9 78.0 15.9 75.5 15.4 73.0 15.0 68.0 14.0
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
Note1: is shown as reference.
When selecting the unit models, avoid the Outdoor air temperature range shown by .
Note2: The above table shows the average value of conditions which may occur.
