ED34-645B Control System
Control 717
16
3.6.6 Number of Connectable Units
Note:
1. When you have a 2 central control system (to control one system from 2 central locations), 2 intelligent Touch
Controllers, 4 central remote controllers and 16 unified ON/OFF controllers can be connected. However, a
maximum of 128 units can only be controlled.
2. When you connect 8 or more central control equipment, it is required to satisfy the following conditions. (The
following conditions are not required to be considered when the number of controller is 7 or less.)
Central control equipment + Indoor units + Outdoor units + other adaptors ≤ 160 units
Central Conversion number of central control equipment (
∗) + Indoor units + Outdoor units + other
adaptors ≤ 200 units
(Note: (
∗) is converted one central control equipment except unified ON/OFF controller as 10 units.)
3. When BS unit is installed, BS unit is not counted in the number. However, the indoor units after BS unit should be
counted.
4. The outdoor unit is limited up to a maximum of 10 units and the total rated capacity should be 280kW (100HP) or
less, and also the number of function units is also limited up to 5. However, if the sequential start setting is
possible, up to 10 function units can be connected.
5. When the parallel interface is connected, the number of indoor units are limited up to 64 groups (128 units). When
you judge whether the number of the connectable units is possible, refer to the flow chart on the next page.
Central Control Equipment Indoor Unit Outdoor Unit Other Adaptors
Target Controller (Max. Number)
Central remote controller
(2 units) (Note 1)
intelligent Touch Controller
(2 units) (Note 1)
Unified ON/OFF controller
(8 units) (Note 1)
Schedule timer (1 unit)
Interface for use in BACnet
®
(1 unit)
Parallel interface (4 units)
Intelligent Manager II (1 unit)
Interface for use in
L
ON
W
ORKS
®
(1 unit)
VRV system
SkyAir series
(Interface adaptor for SkyAir
is required.)
HRV unit
Packaged air-conditioner
(FD, UAT, etc.)
(Wiring adaptor for other air-
conditioner is required.)
Room air-conditioner
(Wiring adaptor for other air-
conditioner is required.)
BS unit (Note 3)
Wiring adaptor
Outdoor unit for VRV system
External control adaptor for
outdoor unit
Wiring adaptor for electrical
appendices (1)
Number
of Units
(Note 2) Up to 128 units (Note 5) Up to 10 units (Note 4) Up to 10 units
