ED34-645B Dimensions
RXYQ-P 425
13
2.2 Combination Unit
RXYQ20P, RXYQ22P, RXYQ24P
RXYQ26P, RXYQ28P
Model Name Outdoor Unit 1 Drawing No. Outdoor Unit 2 Drawing No.
RXYQ20P RXYQ12P 3D051450A RXYQ8P
RXYQ8P
3D051449A
3D051449A
3D051449A
3D051449A
3D051449A
RXYQ22P RXYQ12P 3D051450A
3D051450A
3D051450A
3D051450A
RXYQ10P
RXYQ8P
RXYQ10P
RXYQ24P RXYQ16P
RXYQ26P
RXYQ28P
RXYQ18P
RXYQ18P
C : 3D052930A
Unit (mm)
