Control Devices ED34-645B
750 Control
Example: In case of no restriction items from the sub central remote controller while in double central control, make
setting of the Mode No. to "02" and the Switch Setting No. to "0".
Setting Contents and Setting No.
Items indicated by boldface represent the factory set for the No. of Switch Setting.
Do not make setting of any items not listed in the table above.
Refresh function
This function is used to automatically send "OPERATION MODE" and "TEMPERATURE SETTING" from the central
control system while in operation. In order to disable the refresh function, set the "No. of Switch Setting" to "0".
Restriction items from sub central remote controller while in double central control function
While in double central control function, no settings of zone interlock and operation code can be made from the
sub central remote controller. In order to disable the refresh function from the sub central remote controller, set
the "No. of Switch Setting" to "0".
Setting of area designation for forced OFF
• In order to stop all indoor units within the scope of control as a single unit using the entry of T1 and T2, set the
"No. of Switch Setting" to "1".
• In order to stop all indoor units within the scope of control with forced thermostat OFF using the entry of T1 and
T2, set the "No. of Switch Setting" to "2". With this parameter set to "2", no forced stop can be made on any
indoor unit.
4.3.13 Refreshed Operation
Refreshed operation is the function to transmit setting of "Temperature control", "Temperature setting"
automatically from DCS302CA61.
"Refreshed operation" is "ON" when shipped from the factory.
Factory Setting
It depends on the setting of outdoor systems that an indoor unit setting is "Temperature control" or "Temperature
setting"
In case of Refreshed operation is "ON"
• When setting is changed by DCS302CA61, it operates by this setting from the next operation.
If it sets up with 26 °C in cooling by DCS302CA61, "in the case of the equipment which has not carried out zone
setting by a central remote controller, it operates from next with the mode of operation and preset temperature
which were set up on the individual screen."
In the case of the equipment which carried out zone setting, it operates from next with the mode of operation
and preset temperature which were set up on the zone screen.
(Priority is given over the mode of operation and preset temperature which were set up on the zone setting
screen).
When it sets up all at once, it operates from next with the mode of operation and preset temperature which were
set up last time on the individual screen (Equipment which has not carried out zone registration), or the zone
screen.
If a setting change is made with 26 °C of cooling by a central remote controller on an individual screen
(Equipment which has not carried out zone setting)" next operation will also be operated at 26 °C in cooling.
(Even if it has changed into heating operation, fan only operation with wired or wireless remote control, it
operates at 26 °C in cooling.)
Mode No. Setting contents
No. of setting switch
012
00 Setting of sequential operation function NO YES
–
01 Setting of refresh function NO YES
–
02
Setting of restriction items from sub central remote
controller while in double central control function
Disabled Enabled
–
03
Setting of area designation for forced OFF
(Operation with T1 and T2 entered)
Forced OFF all
within the scope of
control
Forced OFF only
within the scope of
control
Forced thermostat
OFF with the scope
of control
04 LED contrast tuning
1234 5 678910
Low
Factory default
High
Outdoor Units Systems Indoor Units Mode
Cooling Mode Cooling 28 °C
Heating Mode Heating 22 °C
Fan Mode Fan Operation
