ED34-645B Guide Specifications
Guide Specifications 869
17
Safety Devices
The following safety devices shall be part of the outdoor unit.
High Pressure Switch, Overload Relay, Inverter Overload Protector, Fusible Plugs.
Oil Recovery System
Unit shall be equipped with an oil recovery system to ensure stable operation with long refrigerant piping.
1.1.2 Indoor Units
Each indoor unit shall be of the Ceiling Mounted Cassette Type (Double Flow), or Ceiling Mounted Cassette Type
(Multi Flow), or Ceiling Mounted Cassette Corner Type, or Slim Ceiling Mounted Duct Type, or Ceiling Mounted Built-
In Type, or Ceiling Mounted Duct Type, or Ceiling Suspended Type, or Wall Mounted Type, or Floor Standing Type,
or Concealed Floor Standing Type, or Ceiling Suspended Cassette Type (Connection Unit Series). It shall have
electronic control valve which control refrigerant flow rate in respond to load variations of the room. The fan shall be
of the dual suction multi blade type and statically and dynamically balanced to ensure low noise and vibration free
operation.
The address of the indoor unit shall be set automatically in case of individual and group control.
In case of centralized control, it shall be set by liquid crystal remote controller.
Control
Computerized PID control shall be used to maintain a correct room temperature.
Unit shall be equipped with a self-diagnosis for easy and quick maintenance and service.
The LCD (Liquid Crystal Display) remote controller shall memorize the latest malfunction code for easy maintenance.
It shall be able to control up to 16 indoor units and change fan speed and angle of swing flap individually in the
group.
Central Remote Controller (Option)
A multi-functional centralized controller (central remote controller) shall be supplied as optional accessory.
It shall be able to control up to 64 zones of 64 groups (each group consists of Max. 16 units) or 128 No.s of indoor
units with the following functions.
a) Temperature setting for each zone, or group, or indoor unit.
b) On / off as a zone or individual unit.
c) Indication of operating condition.
d) Select one of 10 operation modes for each zone.
The controller shall have wide screen liquid crystal display and can be wired by a non-polar 2-wire transmission
cable to a distance of 1 km away from the indoor unit.
Unified ON / OFF Controller (Option)
Unified ON / OFF controller shall be supplied as optional accessory.
It shall be able to control up to 16 groups (each group consists of Max. 16 indoor units) or 128 No.s of indoor units
with the following functions.
a) On/off as a zone or individual unit.
b) Indication of operation condition of each group.
c) Select one of 4 operation modes.
It shall be wired by a non-polar 2-wire transmission cable to a distance of 1 km away from indoor unit.
Schedule Timer (Option)
A schedule timer shall be supplied as optional accessory.
It shall be able to set operation schedule of up to 128 No.s of indoor units.
The operation schedule shall include twice on/off a day and holiday.
It shall be able to set 8 pattern of schedule combined with centralized controller.
Intelligent Touch Controller (Option)
Air-Conditioning management system that can be controlled by a compact all-in-one unit.
Intelligent Manager (Option)
Air conditioner management system (featuring minimized engineering) that can be controlled by personal computers.
