Capacity Tables (Heat Pump High COP Series) ED34-645B
608 RXYQ-PH
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(735)
-19.8 -20.0 76.4 32.4 76.3 33.3 76.1 34.2 76.0 34.6 76.0 35.1 75.8 36.0
-18.8 -19.0 77.8 32.7 77.7 33.6 77.5 34.5 77.4 34.9 77.4 35.3 77.2 36.2
-16.7 -17.0 80.9 33.3 80.8 34.2 80.6 35.0 80.5 35.4 80.5 35.9 80.2 36.7
-13.7 -15.0 84.4 33.9 84.2 34.8 84.0 35.6 84.0 36.0 83.9 36.4 80.2 34.8
-11.8 -13.0 88.2 34.6 88.0 35.4 87.8 36.1 87.8 36.5 86.1 35.9 80.2 33.0
-9.8 -11.0 92.3 35.2 92.1 36.0 92.0 36.7 89.1 35.3 86.1 33.9 80.2 31.2
-9.5 -10.0 94.5 35.5 94.3 36.3 92.1 35.7 89.1 34.3 86.1 33.0 80.2 30.3
-8.5 -9.1 96.5 35.8 96.4 36.5 92.1 34.8 89.1 33.4 86.1 32.1 80.2 29.5
-7.0 -7.6 100.1 36.3 98.0 35.8 92.1 33.2 89.1 32.0 86.1 30.7 80.2 28.3
-5.0 -5.6 104 36.2 98.0 33.7 92.1 31.3 89.1 30.1 86.1 29.0 80.2 26.7
-3.0 -3.7 104 34.1 98.0 31.8 92.1 29.6 89.1 28.5 86.1 27.4 80.2 25.3
0.0 -0.7 104 31.1 98.0 29.0 92.1 27.0 89.1 26.0 86.1 25.1 80.2 23.2
3.0 2.2 104 28.5 98.0 26.6 92.1 24.8 89.1 23.9 86.1 23.0 80.2 21.3
5.0 4.1 104 26.9 98.0 25.1 92.1 23.5 89.1 22.6 86.1 21.8 80.2 20.2
7.0 6.0 104 25.4 98.0 23.8 92.1 22.2 89.1 21.4 86.1 20.7 80.2 19.2
9.0 7.9 104 24.0 98.0 22.5 92.1 21.1 89.1 20.3 86.1 19.6 80.2 18.2
11.0 9.8 104 22.8 98.0 21.4 92.1 20.0 89.1 19.3 86.1 18.6 80.2 17.3
13.0 11.8 104 21.5 98.0 20.2 92.1 18.9 89.1 18.3 86.1 17.7 80.2 16.4
15.0 13.7 104 20.4 98.0 19.2 92.1 18.0 89.1 17.4 86.1 16.8 80.2 15.7
60
(630)
-19.8 -20.0 76.0 34.6 75.9 35.4 75.8 36.2 75.7 36.6 73.8 35.6 68.8 32.7
-18.8 -19.0 77.4 34.9 77.3 35.7 77.2 36.4 76.4 36.3 73.8 34.8 68.8 32.0
-16.7 -17.0 80.5 35.4 80.4 36.2 78.9 35.9 76.4 34.5 73.8 33.2 68.8 30.5
-13.7 -15.0 84.0 36.0 83.8 36.7 78.9 34.1 76.4 32.8 73.8 31.5 68.8 29.0
-11.8 -13.0 87.8 36.5 84.0 34.8 78.9 32.3 76.4 31.1 73.8 29.9 68.8 27.5
-9.8 -11.0 89.0 35.3 84.0 32.9 78.9 30.6 76.4 29.4 73.8 28.3 68.8 26.1
-9.5 -10.0 89.0 34.3 84.0 32.0 78.9 29.7 76.4 28.6 73.8 27.5 68.8 25.4
-8.5 -9.1 89.0 33.4 84.0 31.2 78.9 29.0 76.4 27.9 73.8 26.8 68.8 24.8
-7.0 -7.6 89.0 32.0 84.0 29.8 78.9 27.7 76.4 26.7 73.8 25.7 68.8 23.8
-5.0 -5.6 89.0 30.1 84.0 28.1 78.9 26.2 76.4 25.2 73.8 24.3 68.8 22.5
-3.0 -3.7 89.0 28.4 84.0 26.6 78.9 24.8 76.4 23.9 73.8 23.0 68.8 21.3
0.0 -0.7 89.0 26.0 84.0 24.4 78.9 22.7 76.4 21.9 73.8 21.2 68.8 19.6
3.0 2.2 89.0 23.9 84.0 22.4 78.9 20.9 76.4 20.2 73.8 19.5 68.8 18.1
5.0 4.1 89.0 22.6 84.0 21.2 78.9 19.9 76.4 19.2 73.8 18.5 68.8 17.2
7.0 6.0 89.0 21.4 84.0 20.1 78.9 18.8 76.4 18.2 73.8 17.6 68.8 16.4
9.0 7.9 89.0 20.3 84.0 19.1 78.9 17.9 76.4 17.3 73.8 16.7 68.8 15.6
11.0 9.8 89.0 19.3 84.0 18.1 78.9 17.0 76.4 16.5 73.8 15.9 68.8 14.8
13.0 11.8 89.0 18.3 84.0 17.2 78.9 16.2 76.4 15.6 73.8 15.1 68.8 14.1
15.0 13.7 89.0 17.4 84.0 16.4 78.9 15.4 76.4 14.9 73.8 14.4 68.8 13.5
50
(525)
-19.8 -20.0 74.2 35.8 70.0 33.4 65.8 31.0 63.6 29.8 61.5 28.7 57.3 26.4
-18.8 -19.0 74.2 35.0 70.0 32.6 65.8 30.3 63.6 29.2 61.5 28.1 57.3 25.9
-16.7 -17.0 74.2 33.4 70.0 31.1 65.8 28.9 63.6 27.9 61.5 26.8 57.3 24.7
-13.7 -15.0 74.2 31.7 70.0 29.6 65.8 27.5 63.6 26.5 61.5 25.5 57.3 23.6
-11.8 -13.0 74.2 30.1 70.0 28.1 65.8 26.2 63.6 25.2 61.5 24.3 57.3 22.4
-9.8 -11.0 74.2 28.5 70.0 26.6 65.8 24.8 63.6 23.9 61.5 23.0 57.3 21.3
-9.5 -10.0 74.2 27.7 70.0 25.9 65.8 24.1 63.6 23.3 61.5 22.4 57.3 20.8
-8.5 -9.1 74.2 27.0 70.0 25.3 65.8 23.6 63.6 22.7 61.5 21.9 57.3 20.3
-7.0 -7.6 74.2 25.9 70.0 24.2 65.8 22.6 63.6 21.8 61.5 21.0 57.3 19.5
-5.0 -5.6 74.2 24.4 70.0 22.9 65.8 21.4 63.6 20.7 61.5 19.9 57.3 18.5
-3.0 -3.7 74.2 23.2 70.0 21.7 65.8 20.3 63.6 19.6 61.5 18.9 57.3 17.6
0.0 -0.7 74.2 21.3 70.0 20.0 65.8 18.7 63.6 18.1 61.5 17.5 57.3 16.2
3.0 2.2 74.2 19.6 70.0 18.4 65.8 17.3 63.6 16.7 61.5 16.2 57.3 15.1
5.0 4.1 74.2 18.6 70.0 17.5 65.8 16.4 63.6 15.9 61.5 15.4 57.3 14.4
7.0 6.0 74.2 17.7 70.0 16.7 65.8 15.6 63.6 15.2 61.5 14.7 57.3 13.7
9.0 7.9 74.2 16.8 70.0 15.9 65.8 14.9 63.6 14.4 61.5 14.0 57.3 13.1
11.0 9.8 74.2 16.0 70.0 15.1 65.8 14.2 63.6 13.8 61.5 13.3 57.3 12.5
13.0 11.8 74.2 15.2 70.0 14.4 65.8 13.5 63.6 13.1 61.5 12.7 57.3 11.9
15.0 13.7 74.2 14.5 70.0 13.7 65.8 12.9 63.6 12.5 61.5 12.2 57.3 11.4
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
Note1: is shown as reference.
When selecting the unit models, avoid the Outdoor air temperature range shown by .
Note2: The above table shows the average value of conditions which may occur.
