Test Run ED34-645B
678 Installation of Outdoor Units
13.Test Run
13.1 Before Test Run
• Make sure the following works are completed in accordance with the installation manual.
Piping work
Wiring work
Air tight test
Vacuum drying
Additional refrigerant charge
• Check that all work for the indoor unit are finished and there are no danger to operate.
13.2 Test Run
After check operation is completed, operate the unit normally and check the following.
(1) Make sure the indoor and outdoor units are operating normally.
(2) Operate each indoor unit one by one and make sure the corresponding outdoor unit is also operating.
(3) Check to see if cold (or hot) air is coming out from the indoor unit.
(4) Push the fan direction and strength buttons on the remote controller to see if they operate properly.
• Heating is not possible if the outdoor temperature is 24°C or higher. Refer to the Operation manual.
• If a knocking sound can be heard in the liquid compression of the compressor, stop the unit immediately and then
energize the crank case heater for a sufficient length of time before restarting the operation.
• Once stopping, the compressor will not restart in about 5 minutes even if the On/Off button of the remote
controller is pushed.
• When the system operation is stopped by the remote controller, the outdoor units may continue operating for
further 5 minutes at maximum.
• The outdoor unit fan may rotate at low speeds if the Night-time low noise setting or the External low noise level
setting is made, but this is not a malfunction.
13.3 Checks After Test Run
Perform the following checks after the test run is complete.
• Record the contents of field setting.
→ Record them on the accessory “REQUEST FOR THE INDICATION” label.
And attach the label on the back side of the front panel.
• Record the installation date.
→ Record the installation date on the accessory “REQUEST FOR THE INDICATION” label in accordance with
the IEC60335-2-40.
And attach the label on the back side of the front panel.
After the test run, when handing the unit over to the customer, make sure the EL.COMPO.BOX lid, the inspection
door, and the unit casing are all attached.
