ED34-645B Installation of Outdoor Units
Installation of Outdoor Units 637
15
Do not Use Stands to Support The Corners
In the case of 8HP type or
more, the product cannot be
supported with four corners.
In the case of 5HP type, the
product can be supported
with four corners.
It is need in the case
of 8HP type or more
Center of the product
It is need in the case
of 8HP type or more
Center of the product
≥
100
≥
100
≥
100
≥
100
≥
100
≥
100
