ED34-645B External Static Pressure Setting
Installation of Outdoor Units 681
15
15.External Static Pressure Setting
2P175033C
How to set the unit to high ESP.
(1) Standard external static pressure for VRVIII is 3mm H2O (29.4Pa).
(2) High external static pressure of 8mm H
2O (78.4Pa) is available by field setting as
shown below.
In this case a kind of sound proof device should be considered because of
increasing the operation sound.
