ED34-645B Control System
Control 719
16
Note:
1. When one system is to be controlled from two locations, up to two intelligent Touch Controller (In case of
combining the intelligent Touch Controller and Central Remote Controller, it is restricted to combine two
Controllers in total), four Central Remote Controller and 16 unified ON/OFF Controller can be connected.
However, the maximum number of units that can be controlled is 128.
2. When a BS unit is used, the indoor units used in its downstream are not counted.
3. One port of one Interface for use in BACnet
®
can have up to 64 groups (64 master indoor units with address). In
case of adopting group controlling, the circuit covered by the data station can have up to 128 indoor units
including main and sub units.
