Control Functions ED34-645B
858 Control
3. Wire the Indoor Unit
Connect the terminals on top of the upper part of remote controller (P1, P2), and the terminals of the indoor unit (P1,
P2). (P1 and P2 do not have polarity.)
Note:
When wiring, run the wiring away the power supply wiring in order to avoid receiving electric noise (external noise).
Wiring Specifications
Note:
1. Peel the shield and sheath for the part that is to pass through the inside of the remote controller case, as shown in
the figure below.
2. Treat the terminal for the wire to be connected to the remote controller so the shielded part doesn’t touch any
other part.
4. Reattach the Upper Part of Remote Controller
Be careful not to pinch the wiring when attaching.
Note:
1. The switch box and wiring for connection are not included.
2. Do not directly touch the PC board with your hand.
C : 2PA52602C
Wiring Type Sheathed Wire (2 wire)
Size 0.75 - 1.25 mm²
