Bosch GSK 18 V-LI 0.601.480.300 [13/132] Assembly operation

English | 13

Bosch Power Tools 1 619 929 K10 | (15.7.11)

Assembly

Battery Charging

f Use only the battery chargers listed on the graphics

page. Only these battery chargers are matched to the

lithium ion battery used in your machine.

Note: The battery is supplied partially charged. To ensure

full capacity of the battery, completely charge the battery

in the battery charger before using your power tool for the

first time.

The lithium-ion battery can be charged at any time without

reducing its service life. Interrupting the charging proce-

dure does not damage the battery.

The “Electronic Cell Protection (ECP)” protects the lithium

ion battery against deep discharging. When the battery is

discharged, the power tool is switched off by a protective

circuit: Fasteners can no longer be shot.

After the automatic shut-off of the

power tool, do not continue to press

the trigger. The battery could become damaged.

The battery is equipped with a NTC temperature control

which allows charging only within a temperature range of

between 0 °C and 45 °C. A long battery service life is

achieved in this manner.

Observe the notes for disposal.

Removing the Battery (see figure A)

The battery 8 has two locking levels, which are supposed

to prevent the battery from falling out in case of vibrations

from intensive use.

– Press battery unlocking button 7 (1.) and at the same

time push the battery toward the front.

– Press the battery unlocking button 7 (2.) again and pull

the battery out completely, toward the rear.

Loading the Magazine (see figures B1–B4)

Block the actuation system and remove

the battery before making any adjust-

ments, changing accessories, or placing

the power tool aside. This safety measure

prevents accidental starting of the power

tool.

f Use only original Bosch accessories (see “Technical

Data”). The precision parts of the power tool, such as

the magazine, the outlet and the shot duct, are matched

to Bosch staples, nails and brads. Other manufacturers

use other steel qualities and sizes.

Using fasteners not permitted can damage the power

tool and cause injuries.

While loading the magazine, hold the power tool in such a

manner that the outlet 15 is not pointed at your own body

or at other persons.

– Clean the magazine slider 13 as required and make sure

that the magazine 12 is not dirty/soiled.

– Insert a fitting nail strip 16 in the T-slot at the end of the

magazine 12.

– Push the nail strip in the magazine toward the front until

the last nail is positioned in front of the magazine spring

17.

Note: A lock function of the magazine slider prevents the

power tool from being started with an empty magazine.

The discharge lock-off cannot be pressed in and blank fir-

ing is thus prevented.

– Press the pretensioned nail pusher 14 against the mag-

azine slider 13 and at the same time, pull the magazine

slider completely to the end of the magazine 12.

Note: The magazine slider must slide back with only low

force (finger-pressure). A tight-running magazine slider

causes the nails to be driven in at an incorrect angle.

– With the nail pusher 14 pressed, carefully guide the

magazine slider 13 toward the front until the nail pusher

is over the last nail, thus pushing the nail strip in the

magazine completely to the front.

Note: Do not let the magazine slider snap back without

guiding it. Otherwise, the magazine slider could become

damaged, and there is danger of your fingers being caught

or pinched.

Operation

Actuation system

Single actuation with safety run

With this actuation system, the discharge lock-off 2 must

first be firmly pressed against the workpiece. A fastener is

not discharged until the trigger 6 is pulled.

Afterwards, further discharging procedures can only be ac-

tuated, when the trigger and the discharge lock-off have

first been set back to the starting position.

Starting Operation

Block the actuation system and remove

the battery before making any adjust-

ments, changing accessories, or placing

the power tool aside. This safety measure

prevents accidental starting of the power

tool.

Inserting the Battery

f Use only original Bosch lithium ion batteries with the

voltage listed on the nameplate of your power tool.

Using other batteries can lead to injuries and pose a fire

hazard.

– Insert the charged battery 8 into the handle until it can

be felt to engage and faces flush against the handle.

Shooting Nails (see figure C)

– Firmly position the outlet 15 or the rubber workpiece

protector 1 on the workpiece until discharge lock-off 2

is pressed in completely.

– Afterwards, briefly press trigger 6 and release again.

A nail is discharged.

– Allow the power tool to bounce back from the work-

piece.

– For another driving procedure (shot), completely lift

the power tool from the workpiece and position it firmly

at the next desired location.

f If the trigger 6 and the discharge lock-off 2 are

pressed and held longer than 1 second after firing a

nail, it is possible that further nails are fired due to a

kickback-effect.

Blocking the Actuation System

Block the actuation system before making any adjustments

on the power tool, changing accessories, placing the ma-

chine aside for longer breaks or after finishing work.

Working Advice

Block the actuation system and remove

the battery before making any adjust-

ments, changing accessories, or placing

the power tool aside. This safety measure

prevents accidental starting of the power

tool.

Check the proper function of the safety and actuation de-

vices, and the tight seating of all screws and nuts each time

before using.

Disconnect a defective or not properly operating power

tool immediately from of the power supply and contact an

authorised service agent for Bosch power tools.

Do not perform any incorrect manipulations on the power

tool. Do not disassemble or block any components of the

power tool, such as the discharge lock-off.

Do not carry out “emergency repairs” with unsuitable

means. The power tool is to be maintained regularly and

properly (see “Maintenance and Cleaning”, page 14).

Avoid any tampering and damage to the power tool, e. g.

from:

– Imprinting or engraving,

– Retrofitting measures not approved by the manufactur-

er,

– Guiding along templates manufactured of hard material,

e. g. steel,

– Dropping on or sliding over the floor,

– Using as a hammer,

– Applying any kind of force.

Make sure to check whatever is below or behind your work-

piece. Do not shoot nails into walls, ceilings or floors, when

persons are behind them. The nails can burst through the

workpiece and injure someone.

Do not shoot a nail onto an already driven-in one. This

could cause the nail to deform, the nails could become

jammed or the power tool could move uncontrolled.

When the power tool is used under cold ambient condi-

tions, the first nails will be driven in slower than usual.

Once the power tool has warmed up during working, nor-

mal operating speed will be regained.

Avoid blank shots in order to reduce the wear of the impact

striker.

For longer work breaks or after finishing work, block the

actuation system and empty the magazine if possible.

Emptying the Magazine (see figures D1 – D2)

– With the nail pusher 14 pressed, pull the magazine slid-

er 13 to the rear until the last nail is free; then carefully

guide the magazine slider toward the front to the begin-

ning of the magazine 12.

Note: Do not let the magazine slider snap back without

guiding it. Otherwise, the magazine slider could become

damaged, and there is danger of your fingers being caught

or pinched.

– Turn the power tool so that the nails in the magazine

slide back to the magazine spring 17.

– Push the magazine spring down and allow the nails to

slide past the nail pusher 14 out of the magazine 12.

Adjusting the Depth Stop (see figure E)

The driving depth of the nails can be set with thumbwheel

–Empty the magazine 12.

(See “Emptying the Magazine”, page 13)

– Nails are driven in too deeply:

To reduce the driving depth, turn thumb-

wheel 4 in anticlockwise direction.

Nails are not driven in deep enough:

To increase the driving depth, turn thumb-

wheel 4 in clockwise direction.

– Refill the magazine.

(See “Loading the Magazine”, page 13)

– Test the new driving depth on a test workpiece.

Repeat the worksteps as required.

Clearing Jams (see figures F1 – F2)

Single nails can become jammed in the shot duct. If this

should occur frequently, please contact an authorised

service agent for Bosch power tools.

Note: When the driver blade does not return after clearing

a jam, please contact an authorised service agent for

Bosch power tools.

– Release the trigger

– Block the actuation system (see “Blocking the Actuation

System”, page 13) and remove the battery 8.

–Empty the magazine 12.

(See “Emptying the Magazine”, page 13)

– Press clamping lever 3 down so that the shot duct

opens.

– Remove the jammed nail. For this, us a pair of pliers, if

required.

– Close the shot duct, hang the clip of clamping lever 3 in-

to the hooks on the shot duct and then push the clamp-

ing lever up again.

– Refill the magazine.

(See “Loading the Magazine”, page 13)

ARN

– Press switch 5 toward the left to block

the actuation system.

This prevents a nail from being shot out,

even when the discharge lock-off 2 is po-

sitioned against the workpiece and the

trigger 6 is pulled.

– Press switch 5 toward the right to disen-

gage the actuation system.

The actuation system is now released.

– Press switch 5 toward the left to block

the actuation system.

This prevents a nail from being shot out,

even when the discharge lock-off 2 is po-

sitioned against the workpiece and the

trigger 6 is pulled.
