ESIE05-03 General Functionality
Part 2 – Functional Description 2–21
3
2
4
5
1
Defrost ending
conditions RZQ71
The defrost cycle will be ended when one of the following conditions have been reached :
Defrost ending
conditions
RZQ100~140
The defrost cycle will be ended when one of the following conditions have been reached :
OR
&
&
P 1 minute has elapsed since start of defrost operation
P Outdoor unit heat exchanger temperature ≥ 10°C
P 10 seconds have elapsed since start of defrost operation
P High Pressure ≥ 24,5bar (calculated from LP, inv frequency and PI)
P 10 minutes have elapsed since start of defrost operation
OR
&
&
P 1 minute has elapsed since start of defrost operation
P Outdoor unit heat exchanger temperature ≥ 10°C
P 10 seconds have elapsed since start of defrost operation
P High Pressure ≥ 24,5bar (calculated from indoor unit heat exchanger temperature,
inv frequency and PI)
P 8 minutes have elapsed since start of defrost operation.
&
P 7 minutes have elapsed since start of defrost operation
P Outdoor unit heat exchanger temperature ≥ 6°C
