Daikin RZQ125B7W1B [215/326] Malfunction of outdoor unit fan motor e7
![Daikin RZQ71B8V3B [215/326] Malfunction of outdoor unit fan motor e7](/views2/1794903/page215/bgd7.png)
ESIE05-03 Error Codes: Outdoor Units
Part 3 – Troubleshooting 3–67
33
4
5
1
3.7 Malfunction of Outdoor Unit Fan Motor (E7)
Remote Controller
Display
E7
Method of
Malfunction
Detection
Abnormality of fan motor system is detected according to the fan speed detected by hall IC when the
fan motor runs.
Malfunction
Decision
Conditions
P When the fan runs with speed less than a specified one for 15 seconds or more when the fan motor
running conditions are met
P When connector detecting fan speed is disconnected
P When malfunction is generated 4 times, the system shuts down.
Supposed Causes
P Malfunction of fan motor
P The harness connector between fan motor and PC board is left in disconnected, or faulty connector
P Fan does not run due to foreign matters tangled
P Clearing condition: Operate for 5 minutes (normal)
Troubleshooting
YES
NO
Are fan motor
connectors
disconnected?
NO
YES
Check on connector
of fan motor
(power supply cable)
YES
NO
Is there
any foreign matter
around the fan?
NO
YES
Can
the fan be turned
smoothly with hand after
disconnecting the
fan motor
connector?
Check for pulse input for
number of rotations on the
outdoor unit
PC Board.
Connect the connector.
Remove the foreign matter.
Replace the outdoor unit fan motor.
Replace the outdoor unit fan motor.
Replace the outdoor unit PC board.
Check 5.9.2
Check 5.9.3
ESIE05-03.book Page 67 Wednesday, April 6, 2005 4:09 PM
