ESIE05-03 Outdoor Unit Functional Concept
Part 2 – Functional Description 2–55
3
2
4
5
1
3.3.10 Pressure Difference Control
Outline To ensure the compression ratio (pressure difference between high and low pressure) at low outdoor
temperature conditions in cooling mode and high outdoor temperature conditions in heating mode, the
outdoor fan and target compressor frequency may be varied.
Cooling In cooling low ambient conditions, the outdoor fan speed and compressor frequency will be adapted
to secure the differential pressure between high and low pressure.
Fan control in
cooling
Parameters
∆P > 15bar
Compression ratio > 3.2
Normal control
Upper limit (step 8)
Upper limit (step 8)
Upper limit (step 7)
Upper limit (step 6)
Upper limit (step 5)
Upper limit (step4)
Upper limit (step 3)
Upper limit (step 2)
Upper limit (step 1)
Upper limit (step 0)
= Outdoor fan OFF
Condition B
Condition B
Condition B
Condition B
Condition B
Condition B
Condition B
Condition B
Outdoor fan upper limit : step 8
∆P > 11bar
Compression ratio > 2.4
Condition B
90 seconds have passed
HP > 20bar (RZQ71)
HP > 17bar (RZQ100~14
0)
∆P > 10bar
Compression
ratio >2.2
&
&
&
&
HP > 35 bar (RZQ100~140)
HP > 30 bar (RZQ71)
TA > 27°C
OR
OR
&
&
OR
OR
&
OR
T
Fin
< (T - 15) °C
90 seconds have passed
HP < 16 bar
∆P < 8bar
Compression ratio < 1.8
90 seconds have passed
HP < 16 bar
∆P < 8bar
Compression ratio < 1.8
Condition A
∆P < 9.5bar
Compression ratio < 2.1
HP < 19 bar
TA < 25°C
&
OR
HP > 18 bar
Tfin > T °C
∆P > 9bar
Compression
ratio > 2.0
Condition A
Condition A
Condition A
Condition A
Condition A
Condition A
Condition A
Condition A
RZQ71B8V3B RZQ100~125B8V3B RZQ100~140B7W1B
T°C79°C71°C68°C
ESIE05-03.book Page 55 Wednesday, April 6, 2005 4:09 PM
