![Daikin RZQ125B8V3B [107/326] Pmv control](/views2/1794903/page107/bg6b.png)
ESIE05-03 General Functionality
Part 2 – Functional Description 2–23
3
2
4
5
1
1.16 PMV Control
Outline When the automatic mode is selected on the remote-controller, the unit will automatically activate the
PMV control.
The PMV index is a calculated average comfort level.
Refer to ISO 7730 for details.
Function An optimized indoor temperature will be calculated using the following inputs:
P Outdoor air temperature
P Indoor air temperature
P Remote controller set temperature
In practice, the set point will be moved with 1 or 2 degrees whenever the conditions change. This will
result in a combination of power saving and increased comfort level.
PMV control can be disabled by changing the field settings:
From: 11(21)-4-01 to: 11(21)-4-02
