Error Codes: System Malfunctions ESIE05-03
3–96 Part 3 – Troubleshooting
3
1
3
4
5
4.2 Malfunction of Transmission between Indoor and Outdoor Unit (U4 or UF)
Error code U4 or UF
Error generation The error is generated when the microprocessor detects that the transmission between the indoor and
the outdoor unit is not normal over a certain amount of time.
Causes The possible causes are:
P Wiring indoor-outdoor transmission wire is incorrect
P Malfunctioning indoor unit PCB
P Malfunctioning outdoor unit PCB
P Outside cause (noise...).
Troubleshooting 1 Diagnosis of incorrect or broken/disconnected wiring. If the LEDs on the indoor unit PC board are off,
it indicates that the transmission wiring between indoor and outdoor units may be incorrect or
broken/disconnected.
Turn OFF the power supply
once and then ON again.
Measure a voltage between
pins 2 and 3 on the outdoor
unit terminal block.
(Measure this voltage in the
DC range with (–) terminal
connected to 2 and (+)
terminal to 3.)
U4 display is
reproduced.
Is the
Indoor-outdoor
connection wire properly
connected?
Is the
measured voltage
10V or less or 20V
or more?
Proceed to the
following page.
Correct the connection. (Correct
the connection or the type of the
wire.)
External factors (e.g. noises) are
supposed.
Replace the indoor unit PC board.
NO
NO
YES
YES
NO
