Daikin RZQ125B7W1B [241/326] Abnormal power supply voltage u2
![Daikin RZQ100B7W1B [241/326] Abnormal power supply voltage u2](/views2/1794903/page241/bgf1.png)
ESIE05-03 Error Codes: Outdoor Units
Part 3 – Troubleshooting 3–93
33
4
5
1
3.23 Abnormal Power Supply Voltage (U2)
Remote Controller
Display
U2
Method of
Malfunction
Detection
Malfunction is detected according to the voltage of main circuit capacitor built in the inverter and power
supply voltage.
Malfunction
Decision
Conditions
When the voltage of main circuit capacitor built in the inverter and power supply voltage drop (150-170
VAC) or when the power failure of several tons of ms or longer is generated.
* Remote controller does not decide the abnormality.
Supposed Causes P Drop in power supply voltage (180 V or less)
P Instantaneous power failure
P Inverter open phase (Phase T)
P Faulty main circuit wiring
P Faulty outdoor unit PC board
P Main circuit parts damaged
ESIE05-03.book Page 93 Wednesday, April 6, 2005 4:09 PM
