ESIE05-03 Specifications
Part 1 – System Outline 1–19
3
1
4
5
Symbols: MCA: Min. Circuit Amps
TOCA: Total Over-current Amps
MFA: Max. Fuse Amps (see note 7)
MSC : Max. current during the starting compressor
RLA : Rated Load Amps
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
kW : Fan Motor Rated Output
Notes: 1 RLA is based on the following conditions:
P Power supply: 50Hz 230V
P Indoor temp. - cooling: 27°C DB/19.0°C WB
P Indoor temp. - heating: 20.0°C DB
P Outdoor temp. - cooling: 35.0°C DB
P Outdoor temp. - heating: 7.0°C DB/6.0°C WB
2 TOCA means the total value of each OC set.
3 Voltage range
Units are suitable for use on electrical systems where voltage
supplied to unit terminals is not below or above listed range limits.
4 Maximum allowable voltage variation between phases is 2%.
5 MCA represents maximum input current.
MFA represents capacity which may accept MCA. (Next lower standard fuse rating, minimum 15A)
6 Select wire size based on the larger value of MCA or TOCA.
7 MFA is used to select the circuit breaker and the ground fault circuit interruptor. (earth leakage circuit breaker)
FCQ140DV3B RZQ140B7W1B 50-400
Max.50Hz-440V
Min.50Hz-360V
14.2 14.2 20 12.9 12.9 0.07+0.07 0.3+0.3 0.120 0.7
FCQ71DV3Bx2 RZQ140B7W1B 50-400 14.1 14.1 20 12.9 12.9 0.07+0.07 0.3+0.3 0.030x2 0.3x2
FCQ71B7V3Bx2 RZQ140B7W1B 50-400 14.7 14.7 20 12.9 12.9 0.07+0.07 0.3+0.3 0.045x2 0.6x2
FCQ50B7V1x3 RZQ140B7W1B 50-400 14.7 14.7 20 12.9 12.9 0.07+0.07 0.3+0.3 0.045x2 0.6x2
FCQ35B7V1x4 RZQ140B7W1B 50-400 15.9 15.9 20 12.9 12.9 0.07+0.07 0.3+0.3 0.045x4 0.6x4
FFQ50B7V1Bx3 RZQ140B7W1B 50-400 15.6 15.6 20 12.9 12.9 0.07+0.07 0.3+0.3 0.055x3 0.7x3
FFQ35B7V1Bx4 RZQ140B7W1B 50-400 15.9 15.9 20 12.9 12.9 0.07+0.07 0.3+0.3 0.055x4 0.6x4
FBQ71B7V3Bx2 RZQ140B7W1B 50-400 15.3 15.3 20 12.9 12.9 0.07+0.07 0.3+0.3 0.125x2 0.9x2
FBQ50B7V1x3 RZQ140B7W1B 50-400 15.6 15.6 20 12.9 12.9 0.07+0.07 0.3+0.3 0.085x3 0.7x3
FBQ35B7V1x4 RZQ140B7W1B 50-400 15.5 15.5 20 12.9 12.9 0.07+0.07 0.3+0.3 0.065x4 0.5x4
FHQ71BUV1Bx2 RZQ140B7W1B 50-400 14.7 14.7 20 12.9 12.9 0.07+0.07 0.3+0.3 0.062x2 0.6x2
FHQ50BUV1Bx3 RZQ140B7W1B 50-400 15.3 15.3 20 12.9 12.9 0.07+0.07 0.3+0.3 0.062x3 0.6x3
FHQ35BUV1Bx4 RZQ140B7W1B 50-400 15.9 15.9 20 12.9 12.9 0.07+0.07 0.3+0.3 0.062x4 0.6x4
FHQ71BUV1Bx2 RZQ140B7W1B 50-400 14.1 14.1 20 12.9 12.9 0.07+0.07 0.3+0.3 0.043x2 0.3x2
FHQ71BUV1Bx2 RZQ140B7W1B 50-400 14.9 14.9 20 12.9 12.9 0.07+0.07 0.3+0.3 0.045x2 0.7x2
Unit combination Power supply Compressor OFM IFM
ESIE05-03.book Page 19 Wednesday, April 6, 2005 4:09 PM
