ESIE05-03 General Functionality
Part 2 – Functional Description 2–9
3
2
4
5
1
1.5 Simulated Operation Function
Outline When a malfunction on one of the below thermistors occurs, operation will continue while displaying
the applicable alarm on the remote-controller. Fin thermistor malfunction is only displayed when
pressing the "Inspection" button on the remote-controller.
Sensors
P Outside temperature thermistor
P Outdoor heat exchanger thermistor
P Fin thermistor
P Discharge pipe thermistor
P Indoor unit air suction thermistor
P Indoor heat exchanger thermistor (RZQ71)
Remark Simulated operation will not be conducted in case the below mentioned thermistors are
malfunctioning:
P Low pressure sensor (RZQ71)
P Suction thermistor
P Indoor heat exchanger thermistor (RZQ100, 125, 140)
P Outdoor heat exchanger thermistor (RZQ100, 125, 140 in heating mode)
ESIE05-03.book Page 9 Wednesday, April 6, 2005 4:09 PM
