ESIE05-03 Outdoor Unit Functional Concept
Part 2 – Functional Description 2–61
3
2
4
5
1
3.4.3 Discharge Pipe Temperature Control
Outline The expansion valve opening will be controlled in order to avoid abnormal high compressor discharge
temperatures (see also compressor operating frequency control).
Details
RZQ71B RZQ100~140B
M°C 95°C 95°C
N°C 80°C
Normal operation
Expansion valve opening
+5 pls/2 min when cooling,
1 min when heating.
Td > M°C
Td < N°C
ESIE05-03.book Page 61 Wednesday, April 6, 2005 4:09 PM
