ESIE05-03 Wiring Diagrams
Part 1 – System Outline 1–43
3
1
4
5
A1P Printed circuit board R1T Thermistor (Air)
A2P Printed circuit board (INV.) R2T Thermistor (Coil)
BS1 Push button switch
(Forced defrost-pump down)
R3T Thermistor (Discharge pipe)
R4T Thermistor (Suction pipe)
C1, C2, C3 Capacitor R5T Thermistor (Power module)
DS1 Dip switch RC Signal receiver circuit
F1U Fuse (T 6.3/250V) S1PH Pressure switch (High)
HAP (A1P, A2P) Light emitting diode
(Service monitor green)
S1NPL Pressure sensor (Low)
TC Signal transmission circuit
H1P (A1P) Light emitting diode
(Service monitor red)
V1R Power module
V2R, V3R Diode module
K1M (A2P) Magnetic contactor V1T IGBT
K1R (A1P) Magnetic relay (Y1S) X6A Connector (Option)
K2R (A1P) Magnetic relay (Y2S) X1M Terminal strip
K2R (A2P) Magnetic relay Y1E Expansion valve
L1R Reactor Y1S 4-way valve
M1C Motor compressor Y2S Solenoid valve
M1F Motor fan Z1C, Z2C, Z3C,
Z4C
Noise filter
PS Power supply
Q1DI Earth leakage breaker (30mA) Z1F Noise filter (with surge absorber)
R1, R2 Resistor
ESIE05-03.book Page 43 Wednesday, April 6, 2005 4:09 PM
