ESIE05-03 Specifications
Part 1 – System Outline 1–13
3
1
4
5
Notes: 1 Nominal cooling capacities are based on:
P Indoor temperature: 27.0°C DB/19.0°C WB
P Outdoor temperature: 35.0°C DB
P Equivalent refrigerant piping: 7.5 m
P Level difference: 0 m
2 Nominal heating capacities are based on:
P Indoor temperature: 20°C DB
P Outdoor temperature: 7.0°C DB/6.0° C WB
P Equivalent refrigerant piping: 7.5 m
P Level difference: 0 m
Refrigerant oil
Type Daphne FVC50K Daphne FVC68D
Charged volume 0.8 l 1.0 l
Piping connections
Liquid quantity 1
Liquid type Flare connection
Liquid diameter (OD) 9.52 mm
Gas quantity 1
Gas type Flare connection
Gas diameter (OD) 15.9 mm
Drain quantity 3
Drain type Hole
Drain diameter (OD) 26.0 mm
Piping length min. 5 m
Piping length max. 50 m 75 m
Piping length equivalent 70 m 95 m
Piping length chargeless 30 m
Additional refrigerant charge See installation manual 4PW21412-1
Installation height difference max. 30.0 m
Max. intern unit level difference 0.50 m
Heat insulation Both liquid and gas pipes
Defrost method Pressure equalising
Defrost control Sensor for outdoor heat exchanger temperature
Capacity control method Inverter controlled
Safety devices
High pressure switch
Fan motor thermal protector
Fuse
Standard accessories Item Tie-wraps
Quantity 2
Standard accessories Item Installation manual
Quantity 1
Specification RZQ71B8V3B RZQ100B8V3B RZQ125B8V3B
ESIE05-03.book Page 13 Wednesday, April 6, 2005 4:09 PM
