ESIE05-03 Error Codes: Outdoor Units
Part 3 – Troubleshooting 3–71
33
4
5
1
3.9 Malfunctioning in Discharge Pipe Temperature (F3)
Remote Controller
Display
F3
Method of
Malfunction
Detection
Abnormality is detected according to the temperature detected by the discharge pipe temperature
sensor.
Malfunction
Decision
Conditions
P When the discharge pipe temperature rises to an abnormally high level
P When the discharge pipe temperature rises suddenly
Supposed Causes
P Faulty discharge pipe thermistor
P Faulty connection of discharge pipe thermistor
P Insufficient refrigerant amount
P Faulty compressor
P Disconnection of discharge pipe temperature thermistor piping
