Daikin RZQ125B7W1B [136/326] Inverter current protection control
![Daikin RZQ125B7W1B [136/326] Inverter current protection control](/views2/1794903/page136/bg88.png)
Outdoor Unit Functional Concept ESIE05-03
2–52 Part 2 – Functional Description
3
1
2
4
5
3.3.7 Inverter Current Protection Control
Outline The compressor operating frequency will be restricted in order to prevent an over-current to the
compressor.
Flow chart
Parameters
Compressor frequency
–1 step/6 sec
Normal operation
Compressor frequency
+1 step/2 min
Inverter current
> step down current
Inverter upper limit frequency
= Maximum frequency
The condition of Inverter current < step down
current continues for 2 minutes
RZQ71B8V3B RZQ100~125B8V3B RZQ100~140B7W1B
P(A) 11.7 A 19.0 A 11.0 A
Q(A) 12.9 A 19.0 A 13.0 A
P Outdoor unit heat exchanger temperature ≥ Indoor unit heat exchanger temperature
P Outdoor unit heat exchanger temperature ≥ 25°C
P Outdoor unit heat exchanger temperature < Indoor unit heat exchanger temperature
P Outdoor unit heat exchanger temperature < 25°C
&
OR
PAQA
ESIE05-03.book Page 52 Wednesday, April 6, 2005 4:09 PM
