Error Codes: Outdoor Units ESIE05-03
3–72 Part 3 – Troubleshooting
3
1
3
4
5
Troubleshooting
Caution Be sure to turn off power switch before connect or disconnect connector, or parts damage may be
occurred.
Is the
discharge pipe
thermistor characteristic
normal?
(*2.)
Is the
discharge pipe
thermistor correctly
connected to PCB
(A1P)?
Is the
discharge pipe
temperature high?
(See *1.)
Is the
discharge pipe
thermistor attached to the
discharge pipe?
Abnormality in refrigerant system such
as gas shortage, faulty compressor, etc.
Conduct inspection
Connect correctly, and operate the unit
again.
Attach the thermistor, and operate the
unit again.
Replace the discharge pipe thermistor.
Replace the outdoor unit PC board.
Model name
RZQ71
RZQ100 ~ 140
Temperature
110˚C
115˚C
NO
YES
NO
YES
YES
NO
NO
YES
*1 Temperature varies depending on model type.
*2 See “Check 5.6” for "Thermistor temperature – resistance conversion table”
