Daikin RZQ125B7W1B [213/326] Compressor motor lock e5
![Daikin RZQ100B8V3B [213/326] Compressor motor lock e5](/views2/1794903/page213/bgd5.png)
ESIE05-03 Error Codes: Outdoor Units
Part 3 – Troubleshooting 3–65
33
4
5
1
3.6 Compressor Motor Lock (E5)
Remote Controller
Display
E5
Method of
Malfunction
Detection
Inverter PC board takes the position signal from UVWN line connected between the inverter and
compressor, and detects the position signal pattern.
Malfunction
Decision
Conditions
The position signal with 3 times cycle as imposed frequency is detected when compressor motor
operates normally, but 2 times cycle when compressor motor locks. When the position signal in 2 times
cycle is detected
Supposed Causes
P Compressor lock
P High differential pressure (2.6MPa or more) starting
P Incorrect UVWN wiring
P Faulty inverter PC board
P Stop valve is left in closed.
ESIE05-03.book Page 65 Wednesday, April 6, 2005 4:09 PM
