ESIE05-03 Troubleshooting
Part 3 – Troubleshooting 3–23
33
4
5
1
1.3.11 Swing flap does not operate
Applicable Models FUQ, FHQ, FAQ100
Method of
Malfunction
Detection
Utilizes ON/OFF of the limit switch when the motor turns.
Malfunction
Decision
Conditions
When ON/OFF of the micro switch for positioning cannot be reversed even through the swing flap
motor for a specified amount of time (about 30 seconds).
Remark Some functions can force the swing flap into a fixed position, altough swing mode is selected on the
remote controller. This is not an unit error, but a control function to prevent draft to the customer.
Before starting the troubleshooting, make sure the swing flap is not forced into such a fixed position.
(e.g. Hot start, defrost operation, thermostat OFF in heating operation or freeze prevention in cooling
operation. For details see "Fan and Flap Operations" on page 2-34 )
Possible Causes
P Faulty swing motor
P Faulty micro switch
P Faulty connector connection
P Faulty indoor unit PC board
