ESIE05-03 General Functionality
Part 2 – Functional Description 2–15
3
2
4
5
1
1.10 Test Run Control
Purpose When operating the RZQ units for the first time after installation, the unit will - depending on the
selected operation mode - perform a test run operation first.
Situation 1 Cooling - first operation after installation in "Cooling mode"
Situation 2 Cooling - first operation after installation in "Test run mode"
Situation 3 Heating - first operation after installation in "Heating mode"
Situation 4 Heating - first operation after installation in "Test run mode"
Remarks
P When running in test run mode, the unit will sense on site installation parameters (e.g.: failure to
open stop valves,..) and indicate the applicable malfunction code if required.
P If the remote controller shows E3, E4 or L8 as an error code, there is possibility that either the stop
valve is closed or the air flow outlet is obstructed.
P Check the inter unit branch wiring connection (1-2-3 wiring) when the error code U4 or UF is
displayed on the remote controller.
P This "Test Run Control" function is only performed after first power on at installation or after first
power on after a pump down by using the pump down switch is.
Cooling thermostat
ON
Cooling operation in
"Test run mode" for 3
minutes
Normal cooling
operation
Cooling Operation by
Test run button
Cooling operation in
"Test run mode" for 3
minutes
Cooling operation in
forced thermostat
ON.
Heating thermostat
ON
Cooling operation in
test run mode for 3
minutes
Normal heating
operation
Heating Operation by
Test run button
Cooling operation in
test run mode for 3
minutes
Heating operation in
forced thermostat
ON.
