ESIE05-03 Error Codes: Indoor Units
Part 3 – Troubleshooting 3–51
4
5
1
3
2.7 Malfunctioning Capacity Setting (AJ)
Error code AJ
LED indications The table below shows the LED indications.
Error generation The error is generated when the following conditions are fulfilled:
Causes The possible causes are:
P Malfunctioning capacity setting adaptor connection
P Malfunctioning indoor unit PCB.
Capacity setting
adaptor
The capacity is set in the PCB’s memory IC. A capacity setting adaptor that matches the capacity of
the unit is required in the following case:
In case the indoor PCB installed at the factory is for some reason changed at the installation site, the
capacity will not be contained in the replacement PCB. To set the correct capacity for the PCB you
have to connect a capacity setting adaptor with the correct capacity setting to the PCB. The capacity
setting for the PCB will become the capacity setting of the adaptor because the capacity setting
adaptor has priority.
Operation HAP (green) HBP (green)
Normal
cc
Malfunctioning
cc
Condition Description
1
P The unit is in operation.
P The PCB’s memory IC does not contain the capacity code.
P The capacity setting adaptor is not connected.
2
P The unit is in operation.
P The capacity that is set, does not exist for that unit.
ESIE05-03.book Page 51 Wednesday, April 6, 2005 4:09 PM
