Daikin RZQ125B7W1B [147/326] Outdoor unit fan speed control
![Daikin RZQ125B7W1B [147/326] Outdoor unit fan speed control](/views2/1794903/page147/bg93.png)
ESIE05-03 Outdoor Unit Functional Concept
Part 2 – Functional Description 2–63
3
2
4
5
1
3.5.1 Outdoor Unit Fan Speed Control
Fan speed control The outdoor fan speed will be controlled in function of the actual outdoor ambient temperature, the
condensation pressure, pressure difference between low and high pressure and compression ratio.
For details please refer to "Pressure Difference Control".
Fan step table
RZQ71
Fan step table
RZQ100
Step Cooling Heating
0 0 rpm 0 rpm
1 200 rpm 200 rpm
2 250 rpm 250 rpm
3 300 rpm 300 rpm
4 360 rpm 360 rpm
5 430 rpm 430 rpm
6 515 rpm 515 rpm
7 620 rpm 715 rpm
8 818 rpm 738 rpm
Cooling Heating
Step M1F M2F M1F M2F
0 0 rpm 0 rpm 0 rpm 0 rpm
1 250 rpm 0 rpm 250 rpm 0 rpm
2 400 rpm 0 rpm 285 rpm 250 rpm
3 285 rpm 250 rpm 335 rpm 300 rpm
4 360 rpm 325 rpm 395 rpm 360 rpm
5 445 rpm 410 rpm 470 rpm 435 rpm
6 545 rpm 510 rpm 560 rpm 525 rpm
7 660 rpm 625 rpm 660 rpm 625 rpm
8 827 rpm 792 rpm 832 rpm 797 rpm
ESIE05-03.book Page 63 Wednesday, April 6, 2005 4:09 PM
