Outdoor Unit Functional Concept ESIE05-03
2–64 Part 2 – Functional Description
3
1
2
4
5
Fan step table
RZQ125~140
Reference See also:
P "Pressure Difference Control" on page 2–55
P "Defrost Operation" on page 2–19
Cooling Heating
Step M1F M2F M1F M2F
0 0 rpm 0 rpm 0 rpm 0 rpm
1 250 rpm 0 rpm 250 rpm 0 rpm
2 400 rpm 0 rpm 285 rpm 250 rpm
3 285 rpm 250 rpm 335 rpm 300 rpm
4 360 rpm 325 rpm 395 rpm 360 rpm
5 445 rpm 410 rpm 470 rpm 435 rpm
6 545 rpm 510 rpm 560 rpm 525 rpm
7 660 rpm 625 rpm 660 rpm 625 rpm
8 850 rpm 815 rpm 842 rpm 807 rpm
ESIE05-03.book Page 64 Wednesday, April 6, 2005 4:09 PM
