Outdoor Unit Functional Concept ESIE05-03
2–46 Part 2 – Functional Description
3
1
2
4
5
Frequency steps The operating frequency for the sky-air RZQ inverter units will be a value chosen from a list with fixed
frequency settings that is programmed in the unit's memory:
Step No. Compressor operation frequency
RZQ71B RZQ100~140B
1 38Hz 41Hz
2 41Hz 44Hz
3 44Hz 48Hz
4 48Hz 52Hz
5 52Hz 55Hz
6 57Hz 58Hz
7 62Hz 69Hz
8 67Hz 72Hz
9 73Hz 78Hz
10 79Hz 84Hz
11 85Hz 90Hz
12 91Hz 94Hz
13 97Hz 98Hz
14 103Hz 102Hz
15 109Hz 107Hz
16 116Hz 112Hz
17 122Hz 117Hz
18 128Hz 123Hz
19 134Hz 131Hz
20 141Hz 139Hz
21 148Hz 147Hz
22 155Hz 155Hz
23 162Hz 164Hz
24 169Hz 174Hz
25 177Hz ---
ESIE05-03.book Page 46 Wednesday, April 6, 2005 4:09 PM
