Pre-Test Run Checks ESIE05-03
4–6 Part 4 – Commissioning and Test Run
3
1
4
5
Setting the address
for the wireless
remote controller
The address for the wireless remote controller is factory set to 1. To change this setting, proceed as
follows:
Step Action
1 Hold down the FILTER RESET button and the TEST button for at least 4 s, to go to field
set mode. The display indicates the field set mode.
2 Press the FAN button to select a multiple setting (A/b), see ‘Multiple settings A/b’ further
in this section. Each time you press the button, the display switches between “A” and “b”.
FILTER RESET
TEST
FAN
ESIE05-03.book Page 6 Wednesday, April 6, 2005 4:09 PM
