Functional Diagrams ESIE05-03
1–32 Part 1 – System Outline
3
1
1
4
5
Allowable pipe
length and heigth
difference
When re-using existing piping, refer to below table for allowable piping length and heigth difference
(figures in brackets are equivalent lengths).
Model RZQ
Liquid pipe
size
71 100 125 & 140
Maximum allowable piping length (*)
Pair: L1
Twin and triple: L1 + L2
Double twin: L1 + L2 + L4
size-down 10 m (15 m)
standard 50 m (70 m) 50 m (70 m) 50 m (70 m)
size-up 25 m (35 m)
35 m (45 m) 35 m (45 m)
Maximum total one-way piping length
Twin: L1 + L2 + L3
––
50 m
50 m
50 m
Triple: L1 + L2 + L3 + L4 ––
Double twin:
L1 + L2 + L3 + L4 + L5 + L6 + L7
––
Maximum branch piping length
Twin: L2
Double twin: L2 + L4
––
20 m
Maximum difference between branch lengths
Twin: L2 - L3
––
10 m
10 m
10 m
Triple: L2 - L4 ––
Double twin: L2 - L3, L4 - L5,
L6 - L7, (L2 + L4) - (L3 + L7)
––
Maximum heigth between indoor and outdoor
All: H1 ––
30 m
Maximum heigth between indoors
Twin, triple and double twin: H2 ––
0.5 m
Chargeless length
All:
L1 + L2 + L3 + L4 + L5 + L6 + L7
size-down 10 m
standard 30 m
size-up 15 m
ESIE05-03.book Page 32 Wednesday, April 6, 2005 4:09 PM
