ESIE05-03 PCB Layout
Part 1 – System Outline 1–51
3
1
4
5
Connectors The table below describes the PCB connectors.
Connector Connected to Description
X1A X1M Terminal strip connector
X3A X205A (on
inverter PCB)
X6A For optional PCB KRP58M51
X12A Y1E Expansion valve
X17A R3T Discharge pipe thermistor
X18A R4T Suction pipe thermistor
X19A R2T Coil thermistor
X20A R1T Air thermistor
X22A Y1S 4-way valve
X26A Connector for spare part adaptor
X28A Y2S Solenoid valve
X64A S1NPL Low pressure sensor
X77A For optional PCB KRP58M51
ESIE05-03.book Page 51 Wednesday, April 6, 2005 4:09 PM
