ESIE05-03 General Functionality
Part 2 – Functional Description 2–5
3
2
4
5
1
4 Outdoor
ambient
R1T Cooling P Outdoor fan speed control
P PMV control
P Pressure difference control
P Overall current protection control
P Preheating operation control (RZQ71)
Heating
P Defrost control
P PMV control
P Forced thermostat OFF
P Overall current protection control
P Preheating operation control (RZQ71)
5 Discharge
pipe
R3T Cooling
P Discharge superheat control
P Expansion valve control
P Crankcase heater / preheating control
Heating
P Expansion valve control
P Crankcase heater / preheating control
6Suction
pipe
R4T Cooling
P Expansion valve control (SH control)
Heating
P Expansion valve control (SH control)
P Suction pipe superheat protection control
7 Inverter
power
module
R5T Cooling
P Outdoor fan speed control
P Inverter fin temperature control
P Pressure difference control
Heating
P Inverter fin temperature control
Ther-
mistor
Location
Wiring
symbol
Mode Function
ESIE05-03.book Page 5 Wednesday, April 6, 2005 4:09 PM
