DFL-2100/DFL-2400 Intrusion Detection System User Manual
6
Starting the System
The Power on/off switch of the DFL-2100/DFL-2400 is located near the power cable. To start
the system, switch it to the ON position. You will be prompted for a login ID and a password
after the system is started.
The login ID is admin and the password is DLink (to change the password, see Change
Password, on page 15)
Setting System Parameters
Once you have accessed the Command Shell with SSH or a terminal connection, press any
key and the following prompt will appear:
Login as: admin
admin@192.168.168.201’s Password:
D-Link IDS -- Protect your network and servers!
1. Setting DFL-2100/DFL-2400 Device IP
>> set system ip <IDS Device IP>
2. Setting DFL-2100/DFL-2400 Gateway IP
>> set system gateway xxx.xxx.xxx.xxx
(XXX.XXX.XXX.XXX is your gateway IP)
3. Setting DFL-2100/DFL-2400 Network mask
>> set system mask xxx.xxx.xxx.xxx
(xxx.xxx.xxx.xxx is your network mask)
4. Setting DFL-2100/DFL-2400 Policy Server IP
>> set psserver ip <Policy Server IP>
Getting Started
Once you have completed the initial setup, as described in the previous chapter, you can
now connect to the DFL-2100/DFL-2400 Policy Server and manage your DFL-2100/DFL-
2400 via web browser.
Connect the DFL-2100/DFL-2400 Policy Server from browser
¾ Open your browser, and enter:
http://<IP Address of the Policy Server>:6592/IDS/
Policy Server Initial Screen
The Initial Screen of Policy Server is the first Web page that you will see when you connect
to the DFL-2100/DFL-2400 Policy Server. This is the main screen for Policy Server; by
clicking on a particular Manu Tab, you can start to use its respective functions:
Manager DFL-2100/DFL-2400 Management System; It allows users to manage
one or more DFL-2100/DFL-2400 devices concurrently. (See DFL-
2100/DFL-2400 Management System)
