DFL-2100/DFL-2400 Intrusion Detection System User Manual
18
get interface
Description: Use the get interface command to display the interface information of DFL-
2100/DFL-2400
Syntax: get interface
Arguments: none
Example:
>>get interface
Remote port: AUTO , MAC address 0:30:64: 1: 8: 2
Local port: AUTO , MAC address 0:d0:b7:b2:5f:ff
>>
get state
Description: Use the get state command to display the state information of DFL-
2100/DFL-2400
Syntax: get log
Arguments: none
Example:
>>get state
State: NORMAL.
>>
get psserver
Description: Use the get psserver command to display the Policy Server’s information,
include IP Address and Log transfer interval time.
Syntax: get psserver
Arguments: none
Example:
>>get psserver
Policy server IP address : 192.168.168.160
Log transfer interval: 30 seconds
>>
get snmp
Description: Use the get snmp command to display the snmp information of DFL-
2100/DFL-2400
Syntax: get snmp [system | community | trap]
Arguments:
system Show the DFL-2100/DFL-2400’s snmp information
community Show the snmp network community setting
trap Show the snmp trap information
Example:
>>get snmp
Options: [ system | community | trap ]
system: Show SNMP System Information
