DFL-2100/DFL-2400 Intrusion Detection System User Manual
6
7
7
7 POLICY DEFINITION PROCESS
In this Chapter we will discuss setting the parameters of books. These books
will be used in Policy definition.
Edit Service Book
DFL-2100/DFL-2400 can support attack detection on the different types of
Services, such as FTP, HTTP, SMTP, and so on. These Services are defined in the
Service Book. DFL-2100/DFL-2400 has predefined several Services commonly seen in
the network. You can also define your own Services and add them to the Service Book.
Click Service Book button
to display the content of Service Book showing in
the Book Table window.
Add a Service
1. Click Service Book button to switch to the Service Book page.
2. Click Add button
or right-click on the Book Table and select Add. The following
dialog appears.
3. Assign a unique Service Name.
4. Assign a unique Color as an identifier in the Reporting System.
5. Select a type (TCP or UDP) from the Service Type pull-down menu.
6. If the type of Service is other than a FTP service, the From Port and To Port field
must be specified, else check the View as FTP Service box and specify the Control
Port and Data Port.
7. Enter your Comment for this Service.
8. Click Add to add the Service to the Service Book.
Note
All the changes to the Service Book will not take effect until the red -
lighted Confirm button is clicked.
