DFL-2100/DFL-2400 Intrusion Detection System User Manual

Figure 6-15: The ”Content Tab”.

Note The extra parameters in the payload don’t matter, too.

For example, given a pattern “/cgi-bin/foo.exe?p1=

abc&p2=def ”.

An URL packet with URL request “/cgi-bin/foo.exe?p0=

xyz&p1=abc&p2=def” is considered as a match.
