D-Link DFL-2400 [83/112] Delete a group

DFL-2100/DFL-2400 Intrusion Detection System User Manual

Modify a Group

1. Click Group Book button to switch to the Group Book page.

2. Click Modify button

or right-click on the Book Table and select Modify.

The following dialog appears.

3. Modify any of these fields as you wish.

4. Click Modify to update this Schedule or Cancel to remain unchanged.

Figure 7-6: ”Modify a Group” Dialog

Delete a Group

Select the entries to be deleted on the Group Book Table and click the Delete

button

or right-click on the table and select “Delete” from the pop-up menu.

Note You cannot delete a Group, which is currently referenced by the

Policy Rules.
