DFL-2100/DFL-2400 Intrusion Detection System User Manual
28
tcp 0.0.0.0.22 0.0.0.0.0 LISTEN
tcp 0.0.0.0.1024 0.0.0.0.0 LISTEN
>>netstat
Proto Local Address Foreign Address (state)
tcp 127.0.0.1.1024 127.0.0.1.9728 ESTABLISHED
tcp 127.0.0.1.9728 127.0.0.1.1024 ESTABLISHED
tcp 192.168.168.201.22 192.168.168.65.2455 ESTABLISHED
reset
Description: Use the reset command to reload the manufacturing default setting. After
reset to default, you must reboot the system to take efface.
Syntax: reset
Arguments: none
Example:
>>reset
Are you sure to reset all settings to manufacturing defaults? (y/n) yes
Reset to defaults OK, please reboot to apply change.
>>
reboot
Description: Use the reboot command to reboot the DFL-2100/DFL-2400 device.
Syntax: reboot
Arguments: none
Example:
>>reboot
Are you sure to reboot system? yes
>>
