DFL-2100/DFL-2400 Intrusion Detection System User Manual
53
Define Policy Action Schedule
At least, you must define when the defense policy will active. The default setting is all
the time.
Figure 5-16: The Schedule Setup
Note The logged attack event will transfer from DFL-2100/DFL-
2400 to Reporting System every fixed time interval. To
change this setting, see the section in DFL-2100/DFL-2400
Console/Telnet System.
Note Only TCP policies will have the option of “Block
Connection”, since other Layer 4 protocol is
ti l
Tip For some policies that are not ambiguous, uncheck “Log
packet headers” will increase the utilization of DFL-
2100/DFL-2400 system.
Note Only Schedule already defined in schedule Book will show in
the combo box. If you want to add a schedule, you have to
define it in the Schedule Book first. See chapter 7 Policy
definition Process
