DFL-2100/DFL-2400 Intrusion Detection System User Manual
54
6
6 DEFINE YOUR OWN
DEFENSE POLICY
Define Your Own Defense Policy
The DFL-2100/ DFL-2400 IDS Management System provides a mechanism that
allows multiple authorities to release attack detection database for DFL-2100/DFL-2400
users. Therefore users can get extensive support from vender or third parties. Check
the “Detect method provider” from Arrange Policies button
to show the policies
group by provider.
Figure 6-1: The Defense Policy database widow
But the DFL-2100/ DFL-2400 Management System also allows users to define
their own policies. Press the “Define a New Policy”
button in the “Defense Policy
database” Window, a “Define New Policy” window will show as following figure.
Note All policies created by users are labeled as “User Defined”. And only “User
Defined” policies can be modified and deleted. Policies issued by vender or third
