DFL-2100/DFL-2400 Intrusion Detection System User Manual
2
2
>>set time
Current time 2002: 4:12 20:43:55 (GMT +8)
Specify year [1980-2050] :
Specify month [1-12] :
Specify date [1-31] :
Specify hour [0-23] :
Specify minute [0-59] :
Specify second [0-59] :
Specify timezone [-12 to +12] :
Change time successfully!
set interface
Description: Use the set interface command to define the physical and logical interface
settings for the DFL-2100/DFL-2400 Device
Syntax: set interface [link|stealth]
Arguments:
link <remote|local|manage><10|100|auto> <full|half>
Define the physical connection mode on the specified
interface as auto sensing whether to operate at full or half
duplex (as required by the device to which it is connected)
stealth <remote|local|manage>
Setting the stealth mode on the specified interface
Example:
>>set interface
Need command: [ link | stealth ]
>>set int
Need command: [ link | stealth ]
set interface link
Description: Use the set interface link command to define the physical connection mode
on the specified interface as auto sensing whether to operate at full or half
duplex
Syntax: set interface link [remote|local|manage] [10|100|auto] [full|half]
Arguments:
<remote|local|manage>
remote Specified remote(WAN) interface setting
local Specified local(LAN) interface setting
manage Specified manage interface setting
<10|100|auto>
10 Set the physical connection at 10 Mbps
100 Set the physical connection at 100 Mbps
auto Setting the physical connection operate mode
by auto sensing
<full|half>
full Setting the physical connection operate mode at
full duplex
