D-Link DFL-2400 [56/112] Network defense policies database

DFL-2100/DFL-2400 Intrusion Detection System User Manual

Network Defense Policies Database

There is a policy database on the Policy Server, administrator can pick up policies

from this predefined database. Or user can click the “Add a Policy” button

on the

toolbar to add a policy to the database.

The “Network Defense Policies Database” window consists of three parts:

 The policy list: List of policies and group by class.

 Attack Attributes: The attack name, ID, type, protected OS and other attack

descriptions.

 Defense Policy: Define the actions when the policy is matched.

Figure 5-6: Network Defense Policies Database

Policy List

Defense Policy

Attributes

Actions
